The main function of the raffia machine is to mechanically process raw materials into slender, soft and elastic raffia filaments. These raffia filaments can be used to fill gift boxes (increasing the sophistication and atmosphere of the gift), make handicrafts, decorate bouquets, etc.
Efficient production: Compared with manual processing of raffia, the machine can achieve continuous and automated operations, greatly improving production efficiency and meeting the market's batch demand for raffia products.
Unified specifications: Through precise cutting and forming devices, the consistency of the length, width, and thickness of the produced raffia yarns can be ensured, improving product quality and aesthetics, and making subsequent uses (such as packaging, decoration) more neat and beautiful.
Strong material adaptability: different types of raffia raw materials can be processed, whether they are natural or fiber materials that have undergone certain pretreatments. As long as they are within the designed processing range of the machine, they can be effectively processed and transformed.
The operation is relatively simple: Generally, operators with simple training can master the operation method of the machine, and can produce raffia products of different specifications by adjusting the parameters through the control panel, which reduces labor costs and technical thresholds.
| Conveyor belt feeding | |
| Specification | Details |
| Paper feed width | 500 mm |
| Slitting width | 3 mm or 4 mm (customizable) |
| Slitting effect | Pleated effect |
| Voltage | Single-phase / Three-phase (customizable) |
| Maximum single cut paper thickness | Approx. 8–10 sheets (70 g) |
| Cutting speed | Approx. 25 m/min |
| Operating noise | 58–60 dB |
| Cutting work noise | 62–65 dB |
| Noise with dust extraction | 68–70 dB |
| Overall dimensions | 730 × 820 × 960 mm |
| Wooden crate dimensions | 810 × 900 × 1100 mm |
| Weight | 240 kg |
| Platform dimensions | Width 800 mm, Depth 540 mm, Height 800 mm |
| Knife shaft material | Alloy steel blade |
| Scraper tooth material | Copper plate precision machined by wire cutting |
| Motor power | 1.5 kW pure copper core gear reduction motor |
| Fan power | 0.75 kW dust extraction fan |
| Casters | Nylon material with brakes |
| Electrical components | CHNT contactors + Yijia start-stop switch |
| Overheat protector | CHNT brand |
| Bearings | Harbin brand |
| Suitable paper | Various papers from 14 g to 350 g |
| Equipped 400 conveyor belt – overall dimensions | 1850 × 800 × 960 mm |
| 400-Type Conveyor Belt | |
| Length × Width × Height | 1700 × 660 × 980 mm |
| Belt surface width | 400 mm |
| Total conveyor table width | 490 mm |
| Maximum paper loading width | 420 mm |
| Drive motor | Variable frequency speed control motor |
| Belt surface material | High-quality rubber |
| Machine body material | Stainless steel |
| Foot cups | Height adjustable |
| Carton size | 1550 × 720 × 420 mm |
| Wooden crate size | 1600 × 780 × 565 mm |
| Net weight | 65 kg |
| Gross weight with wooden crate | 95 kg |
