The main components of this machine are all imported brand components. Strong water pressure and large flow ensure the best washing results. The automatic control system is equipped with a microcomputer control system and a professionally designed and manufactured innovative operation panel to provide the most comfortable operation experience. It can meet the high-standard washing requirements of various plates, dishes, bowls and glasses that meet the specifications.
A 420mm clear height makes washing large dishes more convenient.
A microcomputer-controlled automatic control system ensures easy operation.
The lightest door design requires only 2kg of force to lift, reducing labor.
Uniform wash and spray arms allow tool-free installation and removal.
A sensitive door switch allows for instant cleaning upon closing the door, making it easy and convenient.
Efficient rotating wash and rinse arms maximize pump pressure and reduce water consumption.
Digital temperature control ensures that the spray water temperature reaches or exceeds the disinfection requirement of 82°C during each cycle.
A powerful, self-draining wash pump ensures excellent cleaning and sanitation.
Automatic water level control in the wash tank prevents the heater from drying out. A self-flushing basket and screen assembly facilitate debris collection and removal.
|
Power installation requirements |
380V/50Hz |
|
International copper core diameter |
≥6mm |
|
Inlet pipe diameter |
DN20 |
|
Drainage pipe diameter |
40mm |
|
Inlet pressure |
0.2 - 0.3Mpa |
|
Inlet temperature |
10 - 60℃ |
|
Inlet hardness |
≤60ppm |
|
If installing a hood |
65m³/min |
| Model | TD - 60 |
| Dimensions | 700×701×1440mm |
| Heating method | Electro - thermal |
| Washing amount | 60/40筐/小时(P/h) |
| Total power | 14.65KW/380V |
| Water tank capacity | 20L |
| Washing temperature | 60℃ - 65℃ |
| Rinsing temperature | 82℃ - 90℃ |
| Door opening height | 420mm |
| Water consumption | 2升/筐(L/P) |
